ITEM SHOWN: American Ultra Stratocaster® Left-Hand, Maple Fingerboard, Ultraburst
MODEL #: 0118132712
UPC #: 885978559732
CASE/GIG BAG: Deluxe Hardshell
8lbs 0oz

American Ultra is our most advanced series of guitars and basses for discerning players who demand the ultimate in precision, performance and tone.

The American Ultra Stratocaster Left-Hand features a unique “Modern D” neck profile with Ultra rolled fingerboard edges for hours of playing comfort, and the tapered neck heel allows easy access to the highest register. A speedy 10”-14” compound-radius fingerboard with 22 medium-jumbo frets means effortless and accurate soloing, while the Ultra Noiseless™ Vintage pickups and advanced wiring options provide endless tonal possibilities – without hum. The sculpted rear body contours are as beautiful as they are functional, and the S-1 switch adds the neck pickup in switch position 1 and 2. This versatile, state-of-the-art instrument will inspire you to push your playing to new heights.

Other features include sealed locking tuning machines, chrome hardware and bone nut. Includes premium molded hardshell case.

General
ColorUltraburst
Country Of OriginUS
OrientationLeft-Hand
SeriesAmerican Ultra

Neck
Fingerboard MaterialMaple
Fingerboard Radius10" to 14" Compound Radius (254 mm to 355.6 mm)
Neck FinishUltra Satin Urethane with Gloss Headstock Face
Neck MaterialMaple
Neck ShapeModern "D"
Number of Frets22
Nut MaterialBone
Nut Width1.685" (42.8 mm)
Position InlaysBlack Pearloid Dots
Side DotsBlack
String NutBone

Body
BodyAlder
Body FinishGloss Urethane
Body MaterialAlder
Body ShapeStratocaster®
sku-image

Hardware
Bridge2-Point Deluxe Synchronized Tremolo with Pop-In Arm
Control KnobsAged White Soft Touch Knobs
Hardware FinishNickel/Chrome
Pickguard3-Ply Mint Green
Pickup CoversAged White
StringsFender® USA 250L Nickel Plated Steel (.009-.042 Gauges), PN 0730250403
Switch TipAged White
Tuning MachinesDeluxe Cast/Sealed Locking

Electronics
Auxiliary SwitchingS-1 Switch Down: Position 1. Bridge & Neck. Position 2, 3, or 4: All 3 Pickups On. Position 5. Bridge & Neck
Bridge PickupUltra Noiseless™ Vintage Strat®
ControlsMaster Volume (with S-1™ Switch), Tone 1. (Neck/Middle Pickups), Tone 2. (Bridge Pickup)
Middle PickupUltra Noiseless™ Vintage Strat®
Neck PickupUltra Noiseless™ Vintage Strat®
Pickup ConfigurationSSS
Switching5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup

Miscellaneous
Commodity Code9207901000

Measurements
Dimensions6.10x18.90x44.50 IN
Fret SizeMedium Jumbo
Scale Length25.5" (648 mm)
Shipping Height6.10 IN
Shipping Length44.50 IN
Shipping Weight21.25 LB
Shipping Width18.90 IN
